Analisis Kerusakan Housing Burner Mesin Boiler Type Watertube Kapasitas 2.500 Kg/Jam Di PT. Pratapa Nirmala
DOI:
https://doi.org/10.32497/jmeat.v4i1.7423Abstract
This research focuses on the failure analysis of the housing burner component in a watertube-type boiler with a capacity of 2,500 kg/hour, operated at PT Pratapa Nirmala Pharmaceutical Industry. This study aims to analyze the failure of a housing burner component in a watertube boiler with a capacity of 2,500 kg/h used in the pharmaceutical industry at PT Pratapa Nirmala. Post-operation inspection revealed significant material erosion on one side of the housing burner in the combustion chamber area, which may reduce combustion efficiency and adversely affect the overall boiler performance. To identify the failure mechanisms and root causes, material analyses were conducted on several sample conditions, including worn, non worn, raw material, and heat-treated samples. The investigation involved microstructural observation using optical microscopy and surface morphology analysis using Scanning Electron Microscopy (SEM) to evaluate the extent of surface degradation, the presence of microcracks, oxidation, and porosity. The results indicate that the material degradation is progressive and non-uniform, suggesting an imbalance in heat distribution and combustion gas flow, which is likely associated with misalignment during housing burner installation. Heat treatment was evaluated to assess its potential in improving wear resistance and thermal stability of the material, serving as a basis for technical recommendations regarding design improvement, installation methods, and maintenance strategies for the housing burner.
References
[1] D. Zhang, Y. Hu, and Y. Gao, “Optimization control of a 330 MW drum boiler unit based on DMC algorithm and DEB strategy,” ISA Trans., vol. 128, pp. 435–449, 2022, doi: 10.1016/j.isatra.2021.10.027.
[2] A. S. A. K. Firmansyah, “Desain Pengendalian Ketinggian Air Dan Temperatur Uap Dalam Steam Drum Boiler Menggunakan Discrete Fractional Order PID (FOPID) CONTROLLER,” p. 121, 2015, [Online]. Available: http://repository.its.ac.id/70858/
[3] B. Di and A. Kapal, “Analisis penyebab kegagalan pembakaran pada burner boiler di atas kapal,” 1844.
[4] E. Shobari, “Analisis kerja mesin distilasi dan efisiensi boiler pada pengolahan minyak kayu putih perum perhutani majalengka,” pp. 472–476, 2013.
[5] J. Qin and E. Hu, “The Impact of Solar Radiation on the Annual Net Solar to Power Efficiency of a Solar Aided Power Generation Plant with Twelve Possible ‘configuration-operation’ Combinations,” Energy Procedia, vol. 105, pp. 149–154, 2017, doi: 10.1016/j.egypro.2017.03.294.
[6] S. T. Atmadja, “Analisa Cacat Cor Pada Proses Pengecoran Burner Kompor,” Rotasi, vol. 8, no. 3, pp. 41-46–46, 2006.
[7] A. Cantarero, “Raman Scattering Applied to Materials Science,” Procedia Mater. Sci., vol. 9, pp. 113–122, 2015, doi: 10.1016/j.mspro.2015.04.014.
[8] F. Theil et al., “Ru dye functionalized Au-SiO2@TiO2and Au/Pt-SiO2@TiO2nanoassemblies for surface-plasmon-induced visible light photocatalysis,” J. Colloid Interface Sci., vol. 421, pp. 114–121, 2014, doi: 10.1016/j.jcis.2014.01.029.
[9] P. Singh, D. Deepak, and G. S. Brar, “Optical micrograph and micro-hardness behavior of dissimilar welded joints of aluminum (Al 6061-T6) and stainless steel (SS 304) with friction crush welding,” Mater. Today Proc., vol. 44, pp. 1000–1004, 2021, doi: 10.1016/j.matpr.2020.11.171.
[10] R. T. Dewa, A. Aulia, E. I. Bhiftime, A. N. Satya Permata, I. Farida, and R. Shiraj, “Perancangan Mutakhir Material Propelan Padat dengan Metode Pembuatan Prototipe Cepat,” J. Rekayasa Mesin, vol. 18, no. 1, p. 1, 2023, doi: 10.32497/jrm.v18i1.3877.
[11] V. No, “Efisiensi Termal Water Tube Boiler Berbahan Bakar Gas Dan Solar Pada Produksi Saturated Dan Superheated Steam Berdasarkan Level Ketinggian Air Dalam Steam Drum,” vol. 7, no. 1, pp. 1–7, 2022.
[12] J. T. Mesin, F. Teknik, and U. N. Semarang, “Analisis performa water tube boiler kapasitas 115 ton / jam di PT. Pertamina Refinery Unit VI Balongan-Indramayu,” 2016.
[13] A. Sumalatha, K. S. Rani, and C. Jayalakshmi, “Dynamic modeling of Boiler drum using nonlinear system identification approach,” Meas. Sensors, vol. 28, no. May, p. 100845, 2023, doi: 10.1016/j.measen.2023.100845.
[14] J. Singh, H. Vasudev, S. Singh., “Performance of different coating materials against high temperature oxidation in boiler tubes – A review,” Materials Today: Proceedings, Vol. 26, Part 2, pp. 972-978, 2020, doi: 10.1016/j.matpr.2020.01.156.
